Low Profile Catch Basin Kit

SAVES TIME Less digging
NO MORE exposed extension pipe
QUICK SECURE anchoring system for lawn and yard
SUPER STRONG supports pedestrian traffic

-----

Kit includes:

4 x Anchoring pegs & basin clips

1 x 4in. corrugated pipe adapter

1 x Solid pipe expands to 8 feet

1 x RELN Pop-Up emitter connector

1 x Black grate



13 in. x 13 in. Catch Basin Kit - Black

RELN 13 in. x 13 in. Catch Basin kit is an ideal solution for capturing and managing medium to high runoff water flow with multiple drain line connection points.

The catch basin features 2 x discharge outlets, 2 x 4in. corrugated pipe connectors with knock-out plugs and a unique leaf basket system that prevents pipe blockage. Super-strong light-weight base and grate made from structurally foamed polypropylene, the ideal catch basin to divert water to safe areas away from the home.

  • 5.8 Gal. capacity basin
  • Includes 2 x 4 corrugated pipe connectors with knock-out plugs, 1 x black grate and 1 x debris guard
  • Safe Live Load (kg, lbs, psi) rating: 194kg, 428lbs, 43.4psi
  • Light duty grate classed

Height: 13 in
Width: 13.5 in
Depth: 13.5 in
Weight: 6.6 lbs

10 in. x 10 in. Catch Basin Kit - Black

RELN 10 in. x 10 in. Catch Basin kit is an ideal solution for capturing and managing medium to high runoff water flow with multiple drain line connection points.

The catch basin features 2 x discharge outlets, 2 x 4in. corrugated pipe connectors with knock-out plugs and a unique leaf basket system that prevents pipe blockage. Super-strong light-weight base and grate made from structurally foamed polypropylene, the ideal catch basin to divert water to safe areas away from the home.

  • 2.8 Gal. capacity basin
  • Includes 2 x 4 corrugated pipe connectors with knock-out plugs, 1 x black grate and 1 x debris guard
  • Safe Live Load (kg, lbs, psi) grate rating: 234kg, 515lbs, 52.2psi
  • Light duty grate classed

Height: 10 in
Width: 10 in
Depth: 12 in
Weight: 5 lbs

Product Code: 001118

Soakwell Rapid Flow Kit

The RELN Soakwell is an easy to install and sustainable solution to control storm water runoff.

Used independently or as part of a larger storm water management system, Soakwell units collects, retains and filters storm water naturally through subsurface, reducing pollutants and helping to replenish ground water tables by discharging storm water on site.

  • Clears unwanted water in sandy soil fast, designed to withstand ground pressure, knock out centre or bottom inlet / outlet for controlled flow
  • Drainage slots designed to provide maximum water flow to surrounding soil
  • Kit Includes: 1 x Base Unit, 1 x Lid with inlet & 1 x Filter Sock stops sand from entering Soak Well
  • Dimensions: 24" x 11" x 24"
  • Capacity: 150L

Height: 12 in
Width: 27 in
Depth: 25 in
Weight: 9.95 lbs

18in x 18in x 24in Catch Basin Galvanized Grate

The RELN 18in x 18 in. Catch Basin kit is an ideal solution for capturing and managing high volume runoff water flow and ideal for commercial applications.
  • Super-strong light-weight base made from structurally foamed polypropylene
  • Templates tattooed on base for connection to stormwater pipes
  • With proper installation, supports weight of industrial traffic.
  • Galvanzied metal grate included

Height: 24 in
Width: 17 in
Depth: 17 in
Weight: 8 lbs

13 x 13 x 17 Catch Basin - Black

RELN 13in. x 13in. x 17in. Super-strong light-weight base made from structurally foamed polypropylene, the RELN Catch Basin with black grate is designed for both commercial and domestic applications.

Ideal for many areas around the property as an efficient solution for capturing and managing high volume runoff water. Template tattooed on the base for various pipe dimensions, allows for easy installation.

  • Templates tattooed on base for connection to stormwater pipes
  • Dimensions: 14 inch L x 14 inch W x 17 inch H
  • Catch Basin Capacity 32L

Height: 18 in
Width: 13.5 in
Depth: 13.5 in
Weight: 8 lbs

6in Square Green Grate

The RELN 6 inch Square Green Grate is injection-molded from structural foam polypropylene for high durability.

Ultraviolet inhibitors are added to prevent fading and cracking from exposure to sunlight. Grate is designed to connect into the RELN Bullet Catch Basins (part 000210 & 000211) and onto 6" PVC Sch. 20 pipe.

  • Snap-fit into RELN bullet basins (part number 000210 and 000211)
  • Use in large lawn areas, large landscape areas and patios
  • Drains and directs excess water

Height: 2.0 in
Width: 5.9 in
Depth: 5.9 in
Weight: 0.4 lbs

SCH 40 Adapt.

The RELN 4 in. Sch. 40 Pipe Adapter is designed to adapt 4 in. Schedule 40 pipe to the RELN Storm Drain channel drains and Vortex catch basin. Made of ABS material, it can glue to the Storm Drain End Outlet and the Vortex Pit bottom outlet. Adapts schedule 40 pipe to sewer pipe.
  • Glues into a storm drain end outlet (part number 003408) and vortex basin bottom outlet (part numbers 000077 and 000250)
  • Glues into 4 in. RELN outlet and glues to 4 in. schedule 40 pipe
  • Easy to assemble and install
  • Tough and durable lightweight ABS plastic
  • 1-piece injection molded
  • For residential applications, rated for in-ground use

Weight: 0.45 lbs
