The RELN 4 inch Corrugated Pipe Adapter is designed to snap into 4 inch drain pipe for making quick and easy connections to the RELN drainage system.

Made of ABS material, it can glue to the Storm Drain End Outlet and the Vortex Pit bottom outlet. Adapts corrugated pipe to sewer and drain pipe.

• Glues into a storm drain end outlet (Part number 003408) and vortex basin bottom outlet (Part numbers 000077 and 000250)
• Tough and durable lightweight ABS plastic
• Snap in fit and glued connection

Height: 1.25 in
Width: 5.94 in
Depth: 5.94 in
Weight: 0.28 lbs

RELN Outdoor Drainage sealer has superior adhesion to most construction materials without the need for a primer. It cures to form a flexible, watertight bond to almost any substrate.

It provides a watertight seal for channel drain, pipe and catch basin connection joints. Bonds PVC to ABS pipe as well, a ideal for sealing the Storm Drain End Caps to the channel drain end to create a watertight connection.

• Lightly sand area where silicone will be applied to create a stronger adhesion
• Bonds to: Galvanized steel Aluminium Steel Vinyl Most plastics Masonry, stone, & concrete Ceramics PVC
• Water resistant before, during, and after cure
• 50 year durability
• 100% Silicone, Low odour

Height: 7 in
Width: 2 in
Depth: 1 in
Weight: 1.5 lbs

Storm Master surface water drainage system is the perfect solution for the collection of high surface water flows, in large domestic and light commercial applications

• Lightweight and durable
• Clip in and out design - no screws required
• Durable UV stabilized polypropylene construction

Height: 10.4 in
Width: 9.45 in
Weight: 0.45 lbs

Storm Master surface water drainage system is the perfect solution for collection of high surface water flows, in large domestic and light commercial applications

• Class B Galvanised Steel Grate with lockdown security
• Large profile channel with specially shaped self cleaning channel base to clear high flows of stormwater
• 10 ton load capacity

• Inline pit is designed for fast easy connection to 1M channel with clip system
• When installed the Inline pit looks like part of the Storm Masta channel
• Class B Galvanised Steel Grate with lockdown security
• Choice of 4 x 150mm outlet locations with ABS inserts for easy gluing of PVC
• Anti-floatation feet stops channel from moving or floating during concrete pour

Height: 10.4 in
Width: 10.8 in
Depth: 20.0 in
Weight:

The heavy-duty Storm Master Pro series drainage system is ideal for the collection of substantial flows of surface water in large domestic and light commercial areas.

With wider, deeper channels, a high-intake, galvanized steel lockdown/anti­ tamper grate and a self-cleaning channel base, Storm Master g gets the job done efficiently. Made from durable, lightweight, recycled plastic, this top-of-the­ line system is also easy to install and connects to a wide range of components.

• Class B galvanized steel grate with lockdown security
• Clip in joints assembly for ease of installation
• Bottom knock-out outlet, designed for 6 in. PVC pipe
• 10 ton vehicle loading with appropriate concrete installation
• Dimensions: 40 in. L x 10.75 in. W x 10.375 in. H
• Large profile channel with specially shaped self-cleaning channel base to clear high flows of storm water
• Strong, durable and lightweight UV stabilized poly propylene channel

Height: 10.4 in
Width: 10.8 in
Depth: 39.4 in
Weight: 31.7 lbs

RELN Slim Inline Drainage Pit is designed to work with the Storm Drain Channel system as an underground catch basin.

The unit includes 4 x knock-out discharge outlet options that accommodates 4 in. PVC pipe. Discharge pipe can be glued to the basin by using transition glue (ABS to PVC). The depth of the Slim Inline pit provides flexibility for interlock stone applications and prefect for high vehicle traffic areas allowing discharge pipe at a safe depth.

• ADA compliant grate
• Storm drain inline pit is designed for fast easy connection to RELN storm drain channels
• ABS construction with multiple discharge outlets, that glue to 4 in. sewer pipe
• 316-stainless steel marine grade
• U shaped channel profile that aids in self-cleaning
• Lock-down feet
• Supports domestic passenger vehicles (with appropriate installation in concrete)
• Dimensions: 13.125 in. L x 10.25 in. H x 4.75 in. W
• Designed for RELN storm drain channel series

Height: 10.125 in
Width: 4.75 in
Depth: 13.5 in
Weight: 1.2 lbs

Eliminate outdoor water runoff and pooling issues with the RELN Storm Drain channel drainage system.

It is easy to install and allows maximum flexibility in solving your drainage requirements around the home or light commercial applications. Typical uses include driveways, pools and walkways wherever excess water and erosion are a problem. The systems design allows maximum flexibility in length of channels, corners and intersections. You can connect Storm Drain Channel to 4 in. sewer pipe with bottom or end outlet connection. Duct tile iron grates have a load rating of class C = 5000 kg and can support forklift traffic.

• Channel lengths are interlocking, no clips required
• Recommended to support 5000 kg heavy duty load rating
• Manufactured from 100% recycled plastic (polypropylene)
• Anti-floatation channel feet prevent floating when encased in fill material
• U shaped channel, corners and tees are designed to prevent water pooling
• Cross braced ribs are designed into the body for strength and rigidity
• End outlet accommodates 4 in. sewer pipe or 4 in. corrugated pipe and/or schedule 40 pipe with adaptor
• Grates clip in and out, no screws required
• Class rating load = class C
• Designed to support forklift wheel base traffic2

Height: 5 in
Width: 4.75 in
Depth: 40 in
Weight: 12 lbs
